VULCANIZED FIBRE FOR ELECTRICAL PURPOSES –
Part 1: Definitions and general requirements
1 Scope
This part of IEC 60667 gives the definitions and general requirements for vulcanized fibre
sheets for electrical purposes. Materials made by combining with an adhesive several
thicknesses of vulcanized fibre are not covered by this
...
