2 Normative references
Replace the existing reference to IEC 61803:1999 and IEC 61803:1999/AMD1:2010, as well
as its associated footnote, with:
IEC 61803:2020, Determination of power losses in high-voltage direct current (HVDC)
converter stations with line-commutated converters
Replace the existing reference to ISO/IEC Guide 25, as well as its associated footnote, with:
ISO/IEC 17025, General requirements for the competence of testing and calibration
laboratories
3 Terms and definitions
3.1.4
valve protective firing
Delete the existing term and definition.
3.2 Valve construction terms
Delete subclause 3.2 and existing terms and definitions 3.2.1 to 3.2.7, without renumbering
subsequent subclauses.
6.3.2 Valve support d.c. voltage test
Replace, in the second sentence of the first paragraph, “50 % of the maximum test voltage”
with “50 % of 1 min test voltage”.
‒ 4 ‒ IEC 60700-1:2015/AMD1:2021
© IEC 2021
Delete, in the second sentence of the first paragraph, “in approximately 10 s”.
6.3.3 Valve support a.c. voltage test
Replace, in the second sentence of the first paragraph, “50 % of the maximum test voltage”
with “50 % of 1 min test voltage”.
Replace, in the second sentence of the first paragraph, “within approximately 10 s” with “in
approximately 10 s”.
7.2 Test object
Replace the existing second paragraph with the following new paragraph:
Individual valves may have to be short-circuited depending on the configuration of the MVU
and objectives of the tests. The stresses on the different valves in the MVU depend on
whether those valves belong to the same phase or to different phases.
7.3.1 MVU d.c. voltage test to earth
Replace, in the first sentence of the second paragraph, “50 % of the maximum test voltage”
with “50 % of 1 min test voltage”.
Delete in the first sentence of the second paragraph “in approximately 10 s”.
7.3.4 MVU lightning impulse test
Replace the existing last paragraph by the following new paragraph:
Subject to agreement between the purchaser and supplier, the MVU lightning impulse test
need not be performed, if it can be shown by other means that:
a) the external air clearances to other valves and to earth are adequate for the lightning
impulse voltage withstand level required, and
a) the lightning impulse withstand between any two terminals of the MVU is adequately
demonstrated by other tests.
8.1 Purpose of tests
Add, at the end of the existing subclause, the following new paragraph:
It should be also noted that the atmospheric correction is not needed in dielectric tests
between valve terminals. However, for valves installed at an altitude exceeding 1 000 m the
valve internal air clearance shall be verified by additional tests under the atmospheric
corrected test voltages. Thyristors and snubber circuits can be replaced by insulating blocks
in these tests.
© IEC 2021
8.3.1 Valve d.c. voltage test
Replace, in the first sentence of the second paragraph, “50 % of the maximum test voltage”
with “50 % of 1 min test voltage”.
Replace, in the first sentence of the second paragraph, “within approximately 10 s” with “in
approximately 10 s”.
Replace the existing formula with:
U = ±U × k
tdv dn 7
8.3.2 Valve a.c. voltage test
Replace, in the second sentence of the first paragraph, “50 % of the maximum test voltage”
with “50 % of 15 s test voltage”.
Replace, in the second sentence of the first paragraph, “within approximately 10 s” with “in
approximately 10 s”.
8.3.3 Valve impulse tests (general)
Replace, under the formula, the line for V with:
DSM
V is the non-repetitive peak off-state voltage of the thyristors;
DSM
9.3.2.4 Heat-run test
Replace, under the formula, "(see 5.1.4 of IEC 61803, 1999)" with "(see 5.1.5 of
IEC 61803:2020)".
9.3.6 Intermittent direct current tests
Replace the existing item b) with:
b) rectifier minimum α operation with mini
...
