EUROPEAN STANDARD
DRAFT
prEN 13282-2
NORME EUROPÉENNE
EUROPÄISCHE NORM
January 2010
ICS 93.080.20 Will supersede ENV 13282:2000
English Version
Hydraulic road binders - Part 2: Normal hardening hydraulic road
binders - Composition, specifications and conformity criteria
Hydraulische Tragschichtbinder - Teil 2: Normal erhärtende
hydraulische Tragschichtbinder - Zusammensetzung,
Anforderungen und Konformitätskriterien
This draft European Standard is submitted to CEN members for enquiry. It has been drawn up by the Technical Committee CEN/TC 51.
If this draft becomes a European Standard, CEN members are bound to comply with the CEN/CENELEC Internal Regulations which
stipulate the conditions for giving this European Standard the status of a national standard without any alteration.
This draft European Standard was established by CEN in three official versions (English, French, German). A version in any other language
made by translation under the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the
same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia,
Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland,
Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
Recipients of this draft are invited to submit, with their comments, notification of any relevant patent rights of which they are aware and to
provide supporting documentation.
Warning : This document is not a European Standard. It is distributed for review and comments. It is subject to change without notice and
shall not be referred to as a European Standard.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION
EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre: Avenue Marnix 17, B-1000 Brussels
© 2010 CEN All rights of exploitation in any form and by any means reserved Ref. No. prEN 13282-2:2010: E
worldwide for CEN national Members.
---------------------- Page: 3 ----------------------
oSIST prEN 13282-2:2010
prEN 13282-2:2010 (E)
Contents Page
Foreword . 3
Introduction . 4
1 Scope . 5
2 NORMATIVE REFERENCES . 5
3 DEFINITIONS . 5
3.1 autocontrol testing . 5
3.2 control period . 6
3.3 characteristic value . 6
3.4 specified characteristic value . 6
3.5 single result limit value . 6
3.6 allowable probability of acceptance . 6
4 HYDRAULIC ROAD BINDER . 6
4.1 General . 6
4.2 Normal hardening hydraulic road binder . 6
5 CONSTITUENTS . 7
5.1 Main constituents . 7
5.2 Minor additional constituents . 8
5.3 Calcium sulfate (Cs) . 8
5.4 Additives . 8
6 CLASSIFICATION . 8
7 REQUIREMENTS . 9
7.1 Mechanical requirements . 9
7.2 Physical requirements . 9
7.2.1 Fineness . 9
7.2.2 Initial setting time . 9
7.2.3 Soundness . 10
7.3 Chemical requirement - Sulfate content . 10
7.4 Composition . 10
7.4.1 Declaration of composition . 10
7.4.2 Requirements . 10
7.5 Durability requirements . 11
8 STANDARD DESIGNATION . 11
9 CONFORMITY CRITERIA . 12
9.1 General requirements . 12
9.2 Conformity criteria for mechanical, physical and chemical properties and evaluation
procedure . 13
9.2.1 General . 13
9.2.2 Statistical conformity criteria . 13
9.2.3 Single result conformity criteria . 16
9.3 Conformity criteria for hydraulic road binder composition . 16
9.4 Conformity criteria for properties of the normal hardening hydraulic road binder
constituents . 17
Annex A (NORMATIVE) . 18
A.1 Terms and definitions . 18
A.2 Principle . 18
A.3 General requirements for testing . 19
A.4 Procedure . 20
ANNEX ZA . 24
ZA.1 Scope and relevant characteristics . 24
ZA.2 Procedure for attestation of conformity of normal hardening hydraulic road binders . 25
ZA.2.1 System of attestation of conformity . 25
ZA.2.2 EC Certificate and Declaration of conformity . 26
ZA.3 CE marking and labelling . 27
2
---------------------- Page: 4 ----------------------
oSIST prEN 13282-2:2010
prEN 13282-2:2010 (E)
Foreword
This document (prEN 13282-2:2010) has been prepared by Technical Committee CEN/TC 51 “Cement and
building limes”, the secretariat of which is held by NBN.
This document is currently submitted to the CEN Enquiry.
This document will supersede ENV 13282:2000.
This document has been prepared under a mandate given to CEN by the European Commission and the
European Free Trade Association, and supports essential requirements of EU Directive(s).
For relationship with EU directive(s), see informative annex ZA which is an integral part of this standard.
The European Standard EN 13282 for hydraulic road binders consists of the following parts :
Part 1 : Rapid hardening hydraulic road binders – Composition, specifications and conformity criteria
Part 2 : Normal hardening hydraulic road binders – Composition, specifications and conformity criteria
Part 3 : Conformity evaluation
3
---------------------- Page: 5 ----------------------
oSIST prEN 13282-2:2010
prEN 13282-2:2010 (E)
Introduction
Depending on the local experience and availability of products and materials, different binders are used for
roadbases and sub-bases, capping layers, soil stabilization and soil improvement in Europe. These include
cements conforming to EN 197-1 and EN 197-4, building limes conforming to EN 459-1 and hydraulic road
binders presently defined in existing national standards or technical approvals.
Hydraulic road binders are finished products, produced in a factory and supplied ready for use. They are
differentiated according to their strength development in normal hardening hydraulic road binders specified in
this standard and rapid hardening hydraulic road binders specified in EN 13282-1. The Part 3 of EN 13282
defines the conformity evaluation procedure for hydraulic road binders according to this standard.
Binders obtained through mixing of their constituents on site are not covered by this European Standard.
Cements, masonry cements and building limes are also outside the scope of this European Standard, as they
are defined in specific European Standards.
4
---------------------- Page: 6 ----------------------
oSIST prEN 13282-2:2010
prEN 13282-2:2010 (E)
1 Scope
EN 13282-2 defines and gives the specifications for normal hardening hydraulic road binders, produced in a
factory and supplied ready for treatment of materials for bases, sub-bases and capping layers as well as
earthworks, in road, railway, airport and other types of infrastructures. They are classified according to their
compressive strength at 56 days. It specifies their mechanical, physical and chemical requirements, together
with the conformity criteria and evaluation procedures to be applied by the manufacturer.
2 NORMATIVE REFERENCES
This European Standard incorporates, by dated or undated reference, provisions from other publications.
These normative references are cited at the appropriate places in the text and the publications are listed
hereafter. For dated references, subsequent amendments to or revisions of any of these publications apply to
this European Standard only when incorporated in it by amendment or revision. For undated references the
latest edition of the publication referred to applies.
EN 197-1 Cement – Part 1: Composition, specifications and conformity criteria for
common cements
EN 197-4 Cement – Part 4: Composition, specifications and conformity criteria for low early strength
blastfurnace cements
EN 459-1 Building lime - Part 1: Definitions, specifications and conformity criteria
EN 459-2 Building lime - Part 2: Test methods
EN 196-1 Methods of testing cement - Part 1: Determination of strength
EN 196-2 Methods of testing cement - Part 2: Chemical analysis of cement
EN 196-3 Methods of testing cement - Part 3: Determination of setting time
and soundness
EN 196-6 Methods of testing cement - Part 6: Determination of fineness
EN 196-7 Methods of testing cement - Part 7: Methods of taking and preparing
samples of cement
EN 13282-1 Hydraulic road binders– Part 1: Rapid hardening hydraulic road binders
EN 13282-3 Hydraulic road binders – Part 3: Conformity evaluation
EN 451-1 Methods of testing fly ash – Part 1: Determination of available lime content
ISO 10694 Soil quality - Determination of organic and total carbon after dry combustion (elementary
analysis)
3 DEFINITIONS
For the purposes of this European Standard, the following definitions apply :
3.1 autocontrol testing
continual testing by the manufacturer of normal hardening hydraulic road binder spot samples taken at the
point(s) of release from the factory/depot
5
