The relationship between wind speed, wind pressure and air volume

Introduction The relationship between wind speed, wind pressure and air volume 1. All three are related to wind 2. There is a certain relationship between the three when one of them remains unchanged in a certain period of time and in a certain space, the wind. the pr

The relationship between wind speed, wind pressure and air volume

1. All three are related to wind

2 There is a certain relationship between the three when one of them remains unchanged

At a certain time within a given time frame. certain space, when the wind pressure remains unchanged: the greater the wind speed, the greater the wind volume;

In a certain period of time, in a certain space, when the volume of The air remains constant: the higher the wind pressure, the greater the wind speed.

Detailed information:

Types of wind speed measuring instruments

①Windproof anemometer. This is the most common type of anemometer. The rotating cup anemometer was first invented by the British J.T.R. Robinson (1846). He used four cups at the time, then moved to three cups. Three empty parabolic or hemispherical cups fixed on the support at 120 degrees from each other are aligned on one side, and the entiresupport as well as the wind cup are mounted on a shaft which can rotate freely.

Under the action of the force of the wind, the wind cup rotates around its axis and its rotation speed is proportional to the wind speed. The rotational speed can be recorded using electrical contacts, tachometer generators or photoelectric meters.

②Propeller anemometer. It is an anemometer with a set of propellers with three or four blades rotating around a horizontal axis. The propeller is mounted on the front of a weather vane so that its plane of rotation always faces the direction of the wind and its speed of rotation is proportional to the wind speed.

③Hot wire anemometer. A metal wire is heated by electric current and the circulating air causes it to dissipate the heat. The linear relationship between the heat dissipation rate and the square root of the wind speed is used, then linearrized via electronic circuits (for easy scaling and reading). ), a hot wire anemometer can be made. Hot wire anemometers are divided into two types: side heating type and direct heating type. Laterally heated hot wires are usually manganese-copper wires, the thermal resistance coefficient of which is close to zero, and on its surface there is a temperature measuring element.

Direct heating hot wires are mainly made of platinum wire, which can directly measure the temperature of the hot wire itself while measuring the wind speed. The hot wire anemometer has high sensitivity to low wind speeds and is suitable for measuring small wind speeds. With a time constant of only a few hundredths of a second, it is an important tool for measuring atmospheric turbulence and agricultural meteorology.

④Acoustic anemometer.The wind speed component in the direction of sound wave propagation will increase (or decrease) the speed of sound wave propagation. An acoustic anemometer made using this feature can be used to measure the wind speed component. Acoustic anemometers have at least two pairs of sensing elements, one for each pair comprising a sounder and a receiver.

Make the sound wave propagation directions of the two sounders in opposite directions. If one set of sound waves propagates along the wind speed component and the other set propagates just against the wind, the time difference between the two receivers is calculated. the reception of the sound pulse will be proportional to the wind speed component.

If two pairs of components are installed simultaneously in the horizontal and vertical directions, the horizontal wind speedzontal, wind direction and vertical wind speed can be calculated respectively. Since ultrasonic waves have the advantages of anti-interference and good directivity, the frequency of sound waves emitted by the acoustic anemometer is mainly in the ultrasonic band.
